Supercritical fluid chromatography (SFC) is a valuable tool prior to comprehensive two-dimensional gas chromatography (GC×GC) analysis to investigate the composition of petroleum vacuum gas oils (VGOs) and selectively analyse phenolic compounds in coal-derived middle distillates. In the first case, a multidimensional SFC system is used to separate saturates, aromatics and polar compounds in a VGO sample, and in the second case a single ethylpyridine stationary phase is sufficient to selectively separate phenols.

Traditional fossil fuel sources are dwindling and new ways to isolate fuels from existing sources are vital. Two methods look particularly promising: converting heavy petroleum fractions into lighter fractions and transforming coal-derived liquids into synthetic fuels that fit engine requirements. These two matrices involve two separate problems. Converting heavy fractions, such as vacuum gas oils (VGOs), into specific groups is difficult because compounds contained in heavy petroleum fractions must be transformed into lighter compounds,

and coal-derived middle distillates have a high phenol content which must be precisely determined if these distillates are to be processed further (1).

These problems can be solved by using a high-resolution technique, such as multidimensional chromatography, which was developed to overcome the limited peak capacity of one-dimensional chromatographic methods (2).

Although comprehensive two-dimensional gas chromatography (GC×GC) (3) is popular in many sectors, including food, biology and environmental, it is still difficult to cope with some complex samples in terms of group-type selectivity and peak capacity. This difficulty has been highlighted in recent work on analysing diesel fuels (4) and heavy petroleum fractions, such as VGOs (5,6). The lack of group-type selectivity is often a result of the limited choice of polar stationary phases. To overcome this problem multidimensional systems incorporating a separation using a dense mobile phase have been suggested as a solution, including a SFC×GC system (7) and an LC×GC system (8–10).

When considering on-line hyphenation of an LC system with a GC or GC×GC system, the key technical issue is the evaporation of the LC mobile phase which must induce a limited reinjection band for GC.

The stop-flow mode via adapted valve-based- or syringe-based interfaces is preferred because of its flexibility (11,12). Although remarkable results have been obtained for edible oils (12) and petroleum samples (11), the total running time remains a major obstacle.

 as the mobile phase seems more compatible with a gas phase dimension than an LC dimension. The improved compatibility of SFC can be attributed to the expansion stage from the supercritical state to the gas state without any loss of the products of interest. Additionally, SFC separations can provide higher selectivity because of the variety of solvent and solutes, and stationary phase interactions, and because they are often faster than LC separations (13).

The hyphenation of SFC with GC has been already demonstrated by the decompression of the supercritical fluid via a restrictor inserted into the GC injection port (14). This was applied using SFC–GC (15). The symbol "–" defines a heart-cutting hyphenation between SFC and GC, and The "×" symbol in SFC×GC (16,17) defines a comprehensive coupling.

Capillary SFC×GC was demonstrated by the pioneering work of Liu et al. (16). The effluent from the first SFC column was received continuously by the second GC column through a thermal desorption modulator (16). Venter et al. proposed a stop-flow SFC×GC system for oil samples analysis (7) with a fast GC dimension.

An additional dimension involving SFC appears to be very complementary to GC×GC systems.

A SFC–GC×GC (18) configuration was designed for the analysis of a diesel sample. The sample was separated into two fractions, which were directly transferred into two distinct GC×GC column sets (SFC–twin-GC×GC). However, the SFC fractions were not managed by a special interface. Therefore, an interface for multidimensional chromatography between SFC and GC was developed. The design provides an integrated solution for the hyphenation of a SFC system and GC×GC system, and can be operated as an SFC system, an SFC–GC system, an SFC–GC×GC system and also as an SFC×GC×GC system (19).

This paper aims to show how this system was used to unravel the complexity of heavy VGOs and to separate phenolic compounds in coal-derived middle distillates.

 The separation of vacuum gas oils by SFC was first studied with a synthetic test mixture prepared in carbon disulphide (Table 1).

 Table 1: Composition of test mixture TM1.

 A vacuum gas oil of an Arian light feedstock was supplied by IFP Energies Nouvelles (Lyon, France) (Table 2). Before injection, it was previously diluted in CS

Table 2: Physical characteristics and elementary composition of the VGO sample studied.

Direct coal liquefaction middle distillate

 To evaluate the potential of different columns to separate phenolic species, a model mixture representative of a coal- derived middle distillate was prepared. Six families of chemical were selected because they were identified in previous works (1,20): Paraffinic, naphthenic, aromatic, furanic, phenolic and nitrogen-containing compounds. For each chemical family a light and a heavy compound was selected (Table 3). The solvent used for the test samples was ethyl acetate and was supplied by VWR (Fontenay-sous-bois, France). Chemicals were provided by different suppliers: Sigma-Aldrich (Saint Quentin Fallavier, France), Merck (distributed by VWR), Alfa Aesar (Schiltigheim, France), TCI (Zwijndrecht, Belgium) and Fluka (Saint Quentin Fallavier, France).

Table 3: Model mixture representative of the coal-derived middle distillate.

 The investigated coal-derived oil was provided by IFP Energies Nouvelles. It consisted of a middle distillate (boiling points range = 200–350 °C) of a coal oil produced by direct liquefaction. The sample used in this study had a hydrogen content of 11.4%

 [by nuclear magnetic resonance (NMR) spectroscopy], a nitrogen content of 0.24%

 (ASTM D4629), a sulphur content of 0.0072%

 [provided by X-Ray Fluorescence (XRF)], and an oxygen content equal to 0.80%

. The refractive index (RI) and density of the sample were 1.5129 (ASTM D1747) and 0.9330 g/cm

 Samples were injected in the instrument through a switching valve equipped with an injection loop of 5 µL. The mobile phase, carbon dioxide (Alphagaz CO

 SFC grade, Alphagaz, Mitry-Mory, France) was delivered by a PU-2080-CO

 pump (Jasco, Bouguenais, France) at a constant flow-rate of 2.5 mL/min. The backpressure was regulated by a BP-2080 pressure regulator (Jasco). The SFC column(s) and tubular connections were introduced in an in-house modified gas chromatograph (GC6890, Agilent Technologies, Massy, France). All two-positions switching valves were managed via a pneumatic controller (6 ports AC6W, VICI, Schenkon, Switzerland). All tubular connections were in stainless steel (1/16" × 0.13 mm, 0.005') (Interchrom, Montluçon, France). All of the valve heads were placed in regulated heat chambers located at the top of the GC chromatograph. The SFC separation was monitored with a flame ionization detector (FID) set at 350 °C. For this purpose, the total supercritical flow-rate was split (about 1:100) by an integral restrictor made in-house (21) using a stainless steel cross union ZT1C (1/16'', 0.25mm, VICI). The SFC was controlled by independent Chemstation software (Agilent Technologies).

 The GC×GC system consisted of an in-house modified 6890 chromatograph (Agilent Technologies) equipped with dual-stage carbon dioxide jets (22). To perform  modulation simultaneously for two column sets (SFC–twin-GC×GC), the columns holder supplied by Thermo (Milan, Italy) was adapted on top of the chromatograph. The 2D modulation was performed at the beginning of the second columns and the modulation period was set at 30 s.

The 2D modulation was managed by a controller built in-house. The GC×GC instrument was equipped with two split/splitless injectors and two FIDs (370 °C, 100 Hz). H

 and air flow-rates were 35 and 400 mL/min respectively. Two GC×GC columns sets were installed. Helium (99.99%) was used as the carrier gas at constant adapted pressure (23). During the transfer of SFC fractions into the GC×GC system, the trapping temperature was set at –30 °C.

Once the SFC fractions were trapped on the GC phases, the oven returned to the initial temperature (100 °C for VGOs and 50 °C for coal-derived products) at 20 °C/min and the analytical ramp was controlled at 2 °C/min up to 370 °C for VGOs analysis and to 280 °C for coal- derived products analysis.

The data processing of 2D contour plots was performed by 2DChrom (Thermo) after raw data transfer as CSV-files. The control of the (i) GC×GC dimension, (ii) the interface including the valves management and (iii) the data acquisition was performed using independent Chemstation software (Agilent Technologies).

 An interface allowing the intermediate sampling of SFC fractions into loops was designed and implemented. The designed interface is shown in Figure 1. It should be noted that none, one, multiple or all of the supercritical effluents coming from the SFC part can be distributed into the GC×GC system.

Figure 1: Schematic of the designed interface for  SFCâGCÃGCÃGC.

The designed interface was introduced in a highcapacity oven supplied by Interchrom (Montluçon, France). To avoid any change in the physical state of the supercritical effluents, the same temperature and pressure conditions as the SFC separation ones were applied across the whole interface. Therefore, all of the tubular connections and the valve heads were placed in the oven using long metal actuators between the valve head in the oven and the motor out of the oven (VICI).

This interface was based on a set of three main valves: V1, V2 and V3. The first two valves (6 ports AC6W, VICI) were managed using a pneumatic controller. V2 is a 12-port valve EMT2CST6UW (1/16", 0.4 mm, 0.016'), supplied by VICI and is resistant to high pressure (up to 345 bar) and temperature conditions (up to 75 °C); six HPLC sampling loops (model SLKCW, VICI) were adapted using the 12 ports of the multi-positions valve. The management of V2 was performed by a microelectric actuator (EMTCA-CE, VICI) directly piloted by the Chemstation software (Agilent Technologies).

 The function of the V1 valve was the sampling management of supercritical effluents coming from the SFC part towards valve V3 (closed) or the multi-positions valve V2.

V2 allowed the sampling or draining of supercritical effluents, by successively switching the rotor position, that is each loop, allowing for their transfer into or from a loop. The volume of the sampling loops depended on the SFC separation and the sampling of supercritical fractions. The optimal volume for the draining of loops was set at 1.5 times their physical volume and at a minimum of 10 mL.

The V3 valve allowed the transfer of supercritical fractions into the GC×GC system, by splitting the total flow-rate using a derivation combined with a restrictor directly inserted in the GC×GC injector (14). V3 was closed when just implementing a single SFC separation, as well as performing a GC×GC run, that is fractions already transferred, to prevent leaks from the inlet septum. Supercritical fractions were expanded at the restrictor tip inside the GC injector, and then solutes were cryo-focused on the first centimetres of the first GC×GC column.

After the transfer of each SFC fraction, the purge valve of the injector was opened to drain the residual CO

 out of the system. When two different columns sets were available in the same GC×GC oven for SFC–twin-GC×GC operation (two different injectors and detectors were used for GC×GC), for each fraction to be transferred from the SFC system, the selection of the GC×GC columns set to be connected to the SFC effluent was performed using another valve (V4) placed between V3 and the two restrictors.

Concerning the transfer of supercritical effluents, the interface described by Levy et al. (14) has been implemented, that is the decompression of the supercritical fluid via a restrictor inserted into the GC injection port. Conditions were maintained at –30 °C for the trapping temperature, 350 °C for the GC injector temperature and 13 mL/min for the restrictor flow-rate. Supercritical mobile phase was depressurized using the integral restrictor before the trapping of solutes on the first centimetres of the cold first column. The splitless mode was used during transfer. Once the transfer was done, the purge valve was opened to release residual CO

 and the oven returned to the initial temperature (100 °C for heavy oils, 50 °C for coal-derived liquids) at a ramp of 20 °C/min; then the analytical ramp could start.

 The selectivity of various stationary phases (Table 4) was studied with the test mixtures MT1 and MT2. Experiments were performed at 35 °C and the backpressure was regulated at 250 bar.

Table 4: Stationary phases studied for the SFC separation.

 For the application for VGOs, a first 2D-GC column set was dedicated to SFC fractions composed of saturated compounds. It consisted of a combination of a non-polar first column: DB1-HT (dimethylpolysiloxane, J&W Scientific, Folsom, USA) (10 m × 0.32 mm, 0.1 µm) and a mid-polar second column, BPX-50, (50% phenyl)polysilphenylene-siloxane, (SGE, Courtaboeuf, France), (0.8 m × 0.1 mm × 0.1 µm). The second column set was specifically dedicated to SFC fractions composed of unsaturated and polar compounds. It consisted in a combination of a DB1-HT (10 m × 0.32 mm, 0.1 µm) and a BPX-50 (1.45 m × 0.1 mm × 0.1 µm).

 For the analysis of phenolic compounds the column set consisted in a polar Solgelwax (30 m × 0.25 mm × 0.25 µm) in the first dimension coupled with a DB-1 (1 m × 0.1 mm × 0.1 µm) in the second dimension. This configuration involving a polar column in the first dimension and an apolar one in the second dimension was supposedly non-orthogonal because retention mechanisms of each dimension are not independant. However, this configuration enabled the separation of phenols from hydrocarbons, but these species could not be classified by carbon atom in the chromatogram in the same way as orthogonal configurations.

 The implementation of a SFC separation before the GC×GC separation must improve on the lack of group-type selectivity observed for the high temperature 2D-GC (HT-2D-GC) analysis of VGOs (24). The resolution between saturated and unsaturated compounds and the selectivity by aromatic rings number needs to be improved in particular. Consequently, a stationary phase study was performed by one- and multidimensional SFC.

 A "conventional" stationary phase [used in adsorption or normal phase (NP) chromatography] is selective enough to perform a group-type SFC separation of light matrices, such as gasoline (25) and even diesel oils (13,26) in saturates, monoaromatics or diaromatics. However, owing to a higher complexity, the chromatographic resolution can be reduced for some diesels (27). To check the possible applications of 1D-SFC to heavy fractions, such as VGOs, several promising selective stationary phases were studied. This was based on potential high π–π or dipolar interactions (28,29) by the stationary phases. After SFC–FID experiments on the test mixture TM1, chromatographic resolutions were calculated between different couples of compounds (Figure 2).
