Gas chromatography (GC) uses a wide range of gases including helium, hydrogen, and nitrogen as the carrier gas. In the U.S., the most common carrier gas is helium, as it provides good separations, is inert, is readily available, and it is safe to use. In many other countries, helium is less available or is very expensive, and hydrogen is commonly employed. In recent years, the availability of helium has decreased and its cost has increased significantly, so many chromatographers have considered switching to the use of hydrogen (1). In this article, we compare the use of helium and hydrogen in GC and discuss the advantages of hydrogen. In addition, we will discuss how a chromatographer can obtain hydrogen in a convenient, safe, and economical manner to meet the needs of the laboratory.

Helium is a minor component of natural gas formed by the natural breakdown of uranium. Fractional distillation of natural gas allows for the purification of helium from the natural gas. The largest helium concentrations found in natural gas are in Texas, Oklahoma, and Kansas. Sites outside the U.S. with high concentrations of helium are in Algeria and Qatar.

Helium has many uses and applications. These include (by order of size) cryogenic cooling (28%), tank purging (26%), welding cover gas (20%), as a controlled atmosphere (13%), leak detection (4%), and for breathing mixtures (2%) (2). The use of the gas as a carrier gas for GC falls under a miscellaneous category and is a relatively small fraction of the available supply. Many larger users of helium are seeing considerable growth in their use of the gas and will need even larger quantities in the future.

Helium is a critical and national resource for the U.S. During World War II, huge caverns were sealed and used to store the helium, creating the USA Helium National Reserves. In 1995, the government decided to allow the sale of 600 million ft

  of helium between January 1, 2005 and January 1, 2015 (The Helium Privatization Act of 1996- Public Law 104-273) (3). Sales are ongoing and continue in the U.S. and to foreign countries, leading to reduced supplies and much higher prices for helium. In addition, breakdowns in manufacturing facilities have also reduced available supplies (4). The end result of the increase in demand and the decrease in supply has required the withdrawal of the gas from the national reserves and there are significant concerns about the ability to obtain helium on a reliable basis. Many users worry more about the ability to obtain helium when they need it than the increased price.

Hydrogen and helium are both very efficient gases to use for GC and chromatographers can switch from one to the other with little to no difficulty. While the nature of the separation is the same with the two gases, the differences in the properties of the two gases will lead to differences in the efficiency of the separation. A plot of the efficiency of a column is a van Deemter (4) (packed column) or Golay (5) (capillary column) plot that depicts the efficiency of a column versus different operating velocities of various carrier gases. The van Deemter equation (equation 1) is used to calculate the height equivalent to a theoretical plate (HETP). It describes the column efficiency or a measure of its ability to separate peaks. The desired HETP value would be the smallest value obtainable.

 µ = linear velocity of carrier gas (mobile phase)

 = A constant that accounts for the effects of "eddy" diffusion in the column. (The

 term is not used with capillary columns because there is only one flow path and no packing material in a capillary column)

 = A constant that accounts for the effect of molecular diffusion of the vapor in the direction of the column axis

 = A constant proportional to the resistance of the column to mass transfer of solute through it.

Figure 1: Plot of HETP versus linear velocity (5).

Figure 1 shows a plot of HETP versus linear velocity and depicts the areas of the plot that represent the

 = Retention time in seconds of a nonretained compound (typically methane).

 term in the van Deemter expression defines the slope of the curve after the minimum (or bottom) or lowest HETP value. It is this slope and the minimum that displays the difference between the use of hydrogen and helium.

From an operational perspective, the HETP values are determined experimentally at various carrier gas velocities. A plot of HETP versus the linear velocity is generated using equation 3 and equation 4.

 = Retention time of the peak being measured

Measure the peak width for packed columns at the base line and for capillary columns at the half height of the peak.

The chromatographer would desire conditions that provide the smallest value for HETP, as this would provide the accumulation of the most plates or optimize the separation power within a column. When looking at the typical plot of HETP versus the linear gas rate (LGR), there is not much difference between the minimum value for the HETP for helium and hydrogen, but there is a large difference for the average linear velocity or linear gas rate values obtained for the HETP minimum for each gas. When using helium with typical capillary columns, the usable range of LGR is 20–30 cm/s, while for hydrogen, we see a much wider range of LGR of 25–65 cm/s. The slope of the HETP versus LGR curve for hydrogen (C term) is smaller than that for helium and shows only a 25% reduction in the optimum HETP value over the 25–65 cm/s range.

Figure 2: Typical plot for various carrier gases with capillary columns (6).

When you switch from helium to hydrogen, there are two options:

Choose to duplicate your analysis using hydrogen with little to no loss of efficiency.

Choose to take advantage of the higher LGR available with hydrogen to speed up your analysis as the higher linear velocity used for hydrogen leads to shorter retention times and a shorter analysis.

Comparing the Use of Hydrogen and Helium at the Same LGR:

 The chromatograms in Figure 3 compare the separation of a complex sample of bacterial acid methyl esters on an Equity-1 column with a linear velocity of 25 cm/s for both helium and hydrogen. Notice that at the same LGRs that even with this complex sample the retention times for these components are about the same.

Figure 3: Separation of bacterial acid methyl esters (6).

The chromatograms shown in Figure 3 shows the separation of bacterial acid methyl esters for helium and hydrogen with the helium being at the optimum LGR for helium and the run for hydrogen also being at 25 cm/s but not at its optimum (hydrogen is the top chromatogram and helium is the bottom chromatogram.) The run shown for hydrogen shows a total run time of 19.5 min. What would this run look like at the optimum of 50 cm/s with hydrogen?

The chromatogram in Figure 4 is the same column run at 50 cm/s using hydrogen at the same program rate as used in Figure 3. The total run time is at 16 min. Though there is an improvement in the reduction of the run time, you do not see a great reduction. This is because this separation is very temperature sensitive and needs a higher temperature program rate to speed it up. To obtain a faster separation you would increase your temperature program rate by close to twice that used for the run in Figure 3. (See later in this article for temperature program concerns.)

Figure 4: Separation of bacterial acid methyl esters using hydrogen (50 cm/s) (6).

 The use of hydrogen provides the chromatographer with a number of benefits:

Increased speed: Increasing the linear flow rate allows for shorter run times, thereby increasing the throughput of a laboratory.

Achieve lower temperature separations: At the faster elution times, it might not be necessary to increase the column temperature run rate. You might be able to lower the maximum temperature needed for the analysis or remain at those temperatures for shorter periods.

Longer column life: Lower temperatures lead to less column bleed and can provide longer column life. In addition, hydrogen is a reducing gas and can remove potential acidic sites inside of the column. The removal of these sites leads to less sample absorption and less phase breakdown (column bleed). The result is a longer usable life for the column.

Environmental concerns: Hydrogen is available readily via the electrolysis of water and is not a critical national resource. In contrast, helium is a by-product of natural gas or petroleum production and there are environmental concerns with the production and purification of the gas. Hydrogen is a green gas in that its production does not contribute to environmental pollution.
