The worldwide shortage of the popular solvent acetonitrile started in the early fall of 2008. Many laboratories were caught unaware of this pending shortage and did not address the problem quickly enough while others who sensed the problem stocked up on the available supply at the time. Unlike methanol and other solvents that are manufactured for industrial use, acetonitrile is available only as a byproduct of another chemical production. Surprisingly, even the solvent companies, who supply high-grade acetonitrile, experienced a shortage of feedstock for their purification and, hence, could not obtain sufficient acetonitrile to address their customer needs, and the scramble was on. Prices have skyrocketed. Since last October, internet blogs and on-line chromatography forums have been discussing and debating the issue, even referring to the shortage as a "conspiracy of solvent companies." Depending upon the laboratory and the country reporting, there was more than a sufficient amount or none at all. Many ideas to handle the "short-term" shortage were floated around, some of which were practical, some of which were off-the-wall. Many of the ideas were generated by commercial entities, some of whom slanted the possible solution to suit their business needs. In this article, I will present an unbiased look at some of the more practical aspects of coping with the acetonitrile shortage. Currently, as of this writing, there is no prediction when normal supplies will resume.

Acetonitrile is a solvent that has favorable properties for many chemical applications. It shows minimal chemical reactivity, low acidity, and is reasonably low boiling. Important for reversed-phase high performance liquid chromatography (HPLC) and hydrophilic interaction liquid chromatography (HILIC) applications is its miscibility with water, wide range of achievable polarities with water mixtures, low viscosity (resulting in low pressure drop, even with water binary systems), and low ultraviolet cutoff (down to 192 nm). For HILIC, large volume percentages of acetonitrile in water are favored and thus, its use can be more affected by the acetonitrile shortage than reversed-phase chromatography. Particularly hard hit are those who do preparative- and process-scale LC purification using acetonitrile eluents. Acetonitrile is also a very popular solvent for sample preparation techniques such as dilution, protein precipitation of biological fluids, and as a good eluent for solid-phase extraction (SPE). Acetonitrile also finds use in solid-phase oligonucleotide–DNA synthesis, for peptide synthesis, and in the manufacturing of drug substances and drug products, sometimes in copious amounts. So there are many reasons why there is concern over limited supplies.

When first reported, there were a couple of reasons why the acetonitrile shortage arose so quickly. One of the first reports was that during the 2008 Summer Olympics, Chinese factories where acetonitrile was produced as a synthetic by-product were shut down to minimize air pollution. One of the plants was reportedly the largest producer of acetonitrile in China. Some of the factories have not returned to production. Secondly, the September 2008 Hurricane Ike in the Texas Gulf Coast temporarily shutdown one of the major producers in Texas. This facility also had planned a shutdown in production for a factory update and expansion in January 2009. To add to the problem, this company is reported to be in financial difficulty. But the general consensus is that the worldwide demand for acrylonitrile has decreased severely due to the economic downturn.

It turns out that acetonitrile is a minor by-product of the manufacturing of acrylonitrile using the Sohio process. About 2–4% of the Sohio process results in the formation of acetonitrile that is then removed and purified for further use. Most manufacturers of acrylonitrile incinerate this by-product as fuel rather than trying to reclaim it. So, there are a limited number of acrylonitrile producers who reclaim the acetonitrile.

Acrylonitrile has been used widely in plastic products such as polyacrylonitrile and acrylonitrile-butadiene-styrene (ABS) resins. These products are used in automobile manufacturing (bumpers and other parts), carpeting, acrylic and carbon fibers, luggage, small appliances, telephones, computer housings, and other industries. Obviously, the reduced purchase of cars, the housing slump, and purchase of other consumer products has decreased the demand for acrylonitrile-based plastics and production has been curtailed. There also have been reports of a decrease in demand due to acrylic fibers losing market share to polyester fibers. With a large amount of pharmaceutical manufacturing moving to China and India, some of the acetonitrile production will stay in Asia, and that could be another factor in influencing the worldwide availability of acetonitrile down the road.

Thus, because the amount of acetonitrile is proportional to the reduction in acrylonitrile production, there is currently a shortage of this widely used solvent, relative to a year ago. There are other synthetic routes to produce acetonitrile but many of them are not as economical as that obtained from the acrylonitrile process. However, there have been some reports that opportunistic entrepreneurs in China are considering starting production of acetonitrile by alternative methods.

What Are The Consequences of The Acetonitrile Shortage?

Referred to as "The Great Acetonitrile Shortage" or "The Great Acetonitrile Drought" thereby creating "Acetonitrile Anxiety," obviously, when a commodity product falls in supply and the demand still exists, there are going to be cost consequences. The current prices for high-quality and HPLC-grade acetonitrile have gone through the roof with quotes of over $1000 for a 4 X 4-L case fairly commonplace. Price gouging seems to be in fashion. Prices have risen by factors of 6–8 since the summer of 2008. Distributors and suppliers are allocating their available supplies to favored customers based upon their past purchases. In some cases, laboratory chemical suppliers have not been selling this solvent at all, especially to new customers. In some parts of the world, supplies are not even available and deliveries as long as six months have been quoted. In other places, supplies seem to be recovering and prices moderately reduced. The general feeling is that acetonitrile prices will never return to 2008 levels.

Besides price gouging, another consequence of the shortage is that a number of speculators are showing up on internet blogs offering large quantities of bulk acetonitrile of questionable or unknown purity. Most avoid such transactions that also could raise suspicions when importing large amounts of solvent from abroad.

Some feel that the acetonitrile crisis is a "wake-up" call and that laboratories should now develop short-term and long-term strategies to come up with alternative solvent systems. The movement to "greener" solvent systems or miniaturized liquid-phase chromatographic systems could be a positive outcome.

Those most concerned about the acetonitrile shortage are those who work in regulated laboratories, particularly in the pharmaceutical industry. The United States Food and Drug Administration has received many inquiries related to the shortage of acetonitrile, most of which revolve around substituting an alternative solvent to use to validated methods. Their comment on this issue can be found in reference (1). Basically, they have maintained their position that "regardless of the changes a firm makes to address the (acetonitrile) shortage, appropriate method validation and compliance with relevant good manufacturing practices (CGMPs) are necessary" (1).

The most obvious consequence is that many laboratories are looking for a continued supply to maintain their current methods. In the absence of meeting their acetonitrile demands, they are looking for alternatives that can solve their analytical or synthetic problems with a minimum disruption. We will now explore approaches that can be used to eliminate or minimize the use of acetonitrile in their laboratory. We will not address those who use large amounts of acetonitrile in their manufacturing or synthesis processes.

Methods to Reduce HPLC Use of Acetonitrile Based Upon Changing Column Dimensions or Particle Size

Shorter columns with the same internal diameter:

 Depending upon the resolution of your important analytes of your current method, you might be able to reduce the length of your column without sacrificing the method resolution requirements. Because column length (

), when you reduce the column length and keep the flow rate constant, the amount of solvent required is proportionally reduced. Thus, for an isocratic separation, cutting the column in half, separation time and solvent required is halved. However, there is a proportional loss in theoretical plates (

), but because resolution is proportional to

, one does not sacrifice as much resolution as you might think and the separation might be sufficient.

However, for gradient elution, if one cuts the column in half, the gradient time must be reduced proportionally also. Otherwise, your method can be compromised. When changes are made in column length, column internal diameter, flow rate, the change from the initial composition to the final composition, and gradient time, conditions must be adjusted to satisfy equation 1. According to equation 1, which refers to the apparent

*), a change in length must be accompanied by a proportional change in gradient time (

So, if the column length is decreased by a factor of two, then

 must be reduced to ½ to obey equation 1. If, in addition, one would choose to speed up the separation by an increase in flow rate by a factor of two, then

 would be further decreased by a factor of two. Such a twofold change in conditions can have a detrimental effect on resolution but it could be tested easily.

 The use of smaller particles packed into shorter columns is the current trend in higher throughput LC. In this case, a reduction in length is accompanied by a proportional reduction in particle size to maintain separation efficiency and perhaps resolution as well. Because

, there is a loss of plates in going to shorter columns but

 is the average particle diameter) and therefore, plates are increased to maintain the overall resolution. Figure 1 provides the separation of some xanthines as an example of increasing speed by simultaneously reducing the column length from 25 cm to 5 cm and particle diameter from 5 μm to 1.8 μm while keeping the flow rate and the column diameter the same. The separation time (

) and the solvent consumption are reduced proportionally with each reduction in

. For this example, the solvent consumption in Figure 1a was 12 mL, in Figure 1b, 4.5 mL, and in Figure 1c, a total of 2.3 mL. Here, the resolution remained more or less the same so there was no sacrifice in method performance but a fivefold solvent savings.

There is one caveat: as one decreases the particle size, there is a slight shift in the minimum of the van Deemter curve so that flow rate might have to be increased slightly to take full advantage of the particle size reduction. Thus, the separation time could be further decreased. The new submicrometer sized particles are particularly attractive here because separation times and reduction in solvent can be up to an order of magnitude compared to longer columns packed with larger particles. I have updated my listing of suppliers of 2-μm and sub-2-μm columns for high-throughput LC (Table I). With a visit to the websites of these companies, one can get method translation equations, calculators, and software to perform the necessary calculations for changing experimental parameters.

Table I: Commercial two and sub-2 Î¼m totally porous HPLC columns*

The new superficially porous packings can provide some of the same advantages with the added benefit of lower pressure drops because column lengths are generally 5 cm and the particles are in the range of 2.7 μm, but the efficiencies noted are in the neighborhood of the sub-2-μm columns.

Reduction of the column internal diameter:

 An easy approach to reducing solvent consumption is changing the internal diameter of the column with or without decreasing the column length. According to equation 1, if one reduces the diameter and desires to keep the same separation time, the flow rate must be reduced proportionally to the inverse of the radius ratios squared. Thus, if a column internal diameter is reduced from 4.6-mm to 3.0-mm i.d. at constant length, then the flow rate would be reduced by (3.0/4.6)

  to a factor of 0.43. Thus, if one originally had a method using 1.0 mL/min and switched to the 3.0-mm i.d. column, the flow rate would be reduced to 0.43 mL/min and there would be resultant solvent savings of 57%. With 3.0-mm columns, almost any modern HPLC instrument could be employed because instrumental extracolumn volumes and gradient delay volumes are sufficiently small enough not to cause method variances. Decreasing column diameter with a concurrent decrease in flow rate (to maintain constant linear velocity) allows the separation time to remain constant, and users should see a very similar chromatogram as the original.

One can continue to reduce the column internal diameter and achieve further reductions in solvent usage. For example, changing from a 4.6-mm i.d. column to a 2.0-mm i.d. column (referred to as microbore or semimicro columns) will result in approximately 80% solvent savings without affecting the separation characteristics. Such a change can be seen in Figure 2, which shows a separation performed on a 4.6-mm column and a 2.1-mm column, both with a 150-mm length. The flow rate was reduced from 1.0 mL/min to 0.2 mL/min. Note that the sample size was reduced from 5 μL to 1 μL because the cross sectional area of the 2.0-mm column is 1/5. In the case of internal diameter reduction, the response increases fivefold if the sample size is injected. To keep the same response, the sample mass injected was decreased proportionally because a concentration-sensitive detector was used. If the same sample volume (at the same concentration) is injected onto the smaller internal diameter column, an increase in sensitivity should result (if no band spreading results from the larger injection volume), which makes microbore columns ideal for sample mass-limited situations.

When one decreases the internal diameter of the column

, the column void volume decreases with the inverse radius ratio squared and peak volumes become smaller. Table II shows the approximate peak volumes at three different

 values for three different column internal diameters at constant length. Note that for the smallest internal diameter column, 2.1 mm, the peaks with low

 values are only a few tens of microliters in volume. For conventional liquid chromatographs, optimized for 4.6-mm i.d. columns, when peak volumes become less than 60 μL, some optimization of extracolumn effects (those volumes outside of the column packing) might be required (see highlighted values in Table II). Some of the hydraulic volumes that might need deceasing are injection volume, tubing volumes from the injector to the column inlet and from the column exit to the detector inlet (0.12–0.13 mm i.d. tubing is recommended), and the detector flow cell volume itself might need to be reduced if peaks with small

 values are to measured. Because the flow rate for 2.0- or 2.1-mm i.d. columns is now much smaller, the gradient delay volume (sometimes referred to as the dwell volume which is the volume from the point of mixing of the gradient solvents to the head of the column) must be decreased. Otherwise, the gradient might take a considerable time to reach the head of the column and extrapolations from the larger column might not be entirely comparable.

Table II: Solvent saver columns can be used on most LC systems without modification (based on peak volume)

As the column internal diameter becomes further reduced to 1.0 mm and below, the system volume must be totally reworked. For this reason, most commercial chromatographs desired for capillary columns have extremely low extracolumn effects and gradient delay volumes including smaller flow cells as standard. In addition, they are designed to work well at flow rates below 100 μL/min.

To illustrate the effect of column internal diameter on solvent usage, peak volumes and flow rates, Table III provides some characteristics of such systems. Today, even nanoLC instruments that operate with extremely low flow rates (a few hundred nanoliters per minute) are available commercially but mostly are applied to proteomics, where samples are mass limited and mass spectrometry is primarily used for detection. These types of systems are the ultimate in solvent savings. With chip-based systems, a liter of acetonitrile could last a month or more!

Table III: Reducing column internal diameter reduces mobile phase use

Smaller internal diameter columns are often harder to pack as efficiently as larger diameter columns, so there can be some differences in plate number that might have some impact on extrapolations of separation data from larger internal diameter to very small internal diameter columns.

In the case of gradient elution, equation 1 still holds true. With a change in both length and internal diameter, both the flow rate and the gradient time will need to be adjusted. Remember, the column volume can be determined by

* constant with the new column and the same gradient conditions, substitute the values for new column dimensions in equation 1.

Reduction of column internal diameter, column length, and particle diameter:

 Of course, one can combine these approaches to provide even more dramatic solvent savings. By such a combination, however, the column void volume can become quite small, necessitating optimization of the instrumental contributions as discussed previously.

Methods to Reduce HPLC Use of Acetonitrile Based Upon Changing Solvent or Stationary Phase

Use of other organic modifiers in reversed-phase HPLC:

 The most obvious change and one of the easiest to implement is to continue to use one's current reversed-phase column and change the organic modifier to a solvent more readily available. The most popular choice is methanol that can be obtained in high-purity suitable at a reasonable cost and is useful for most HPLC applications. Other solvents that have been considered are tetrahydrofuran, isopropanol, ethanol, and n-propanol. These solvents also are available in high purity for HPLC applications. Of these less commonly used organic modifiers, only tetrahydrofuran has some drawbacks, such as chemical stability — that is, peroxide formation for the unstabilized variety — or the presence of stabilizer, butylated hydroxyl toluene (BHT) that can interfere with UV detection and low UV transparency. However, tetrahydrofuran has some excellent solvation properties for polar analytes and is quite effective when blended with small amounts (~5–10%) of methanol. In addition, tetrahydrofuran can be blended to get approximately the same solvent strength (ε

) as acetonitrile. A mixture of 50% methanol, 25% tetrahydrofuran, and 25% acetonitrile works as a substitute for 100% acetonitrile

Methanol has some disadvantages for HPLC use when compared to acetonitrile. Due to its higher viscosity, the column pressure drop will increase. The well-known viscosity versus % methanol in water curves show a maximum viscosity at approximately 45% methanol while acetonitrile–water mixtures show a much lower increase in viscosity as the % acetonitrile increases. So when gradients are run with water–methanol binary solvents, pressures can increase and can approach the maximum operating pressure of the LC system. When substituting methanol for acetonitrile and operating at the same experimental conditions, the higher viscosity of methanol will give lower efficiency and can lead to slightly broader peaks. Methanol shows a higher UV cutoff (~210 nm) than acetonitrile (~192 nm) that limits its usefulness in the low UV region. Probably the biggest factor that one might observe when switching from acetonitrile to methanol is the different analyte selectivities that can occur (see Figure 3, reference 3). The most glaring change was the elution order of these compounds when using acetonitrile as the organic modifier (Figure 3a) compared to methanol (Figure 3b) as a modifier. Not only did the elution order change but peaks 4 and 6 that were well resolved with the acetonitrile–water solvent system were unresolved when methanol–water was used as the mobile phase. Because methanol is a weaker solvent than acetonitrile, note that its percentage had to be increased to have similar retention times. In Figure 3b, one can see that the methanol concentration in the binary mixture was 58% compared to the 39% acetonitrile shown in Figure 3a.

For binary mixtures of water and organic modifiers, a useful nomograph is shown in Figure 4 (4). This figure compares the approximate solvent strength of binary mixtures of water with the popular solvents acetonitrile, methanol, and tetrahydrofuran. Vertical lines in this figure intersect mobile phases having a similar solvent strength. For example, the vertical line at 40% tetrahydrofuran in water intersects the methanol line at 63% and the acetonitrile line at 53%. Thus, to get approximately equivalent retention times (or at least a similar solvent strength), these amounts of organic modifier would have to be blended with water. Thus, tetrahydrofuran is a more powerful modifier than acetonitrile that in turn is more powerful than methanol. If one closely compares the chromatograms of Figures 3a and 3b, it can be seen that the nomograph is only approximate. In addition, this nomograph does not predict selectivity changes, as was noted in Figure 3, nor are the nomographs suitable for ternary mixtures.

A slightly different format was used in Figure 5. Here, a plot that correlates the composition of several water-miscible solvents that could be used to replace acetonitrile is shown (5). This graph adds ethanol, isopropanol, and dimethyl sulfoxide (DMSO) that could be used as modifiers. Both isopropanol and DMSO are quite viscous, so one must carefully observe the column pressure when switching to such solvents. Again, this plot should be used as a starting point in the evaluation of a modified method.
