The analysis of peptides using liquid chromatography–mass spectrometry (LC–MS) for proteomics applications is powerful and can yield tremendously rich data sets. However, the exquisite sensitivity and global applicability of MS detection also makes it prone to contaminants that can easily and seriously compromise the quality of a data set. A short list of tips and tricks can increase the likelihood of consistently producing good LC–MS data in this context and streamline the troubleshooting process when problems do eventually occur.

Some applications of liquid chromatography (LC) involve highly specific “tips and tricks” that are acquired by analysts over time, and they can make the difference between producing data that is either terrible or great. The analysis of peptides by LC coupled with mass spectrometry (LC–MS) is one such area where it can appear that highly skilled analysts possess superpowers or “golden hands” that enable them to acquire better data than anyone else in a laboratory. In the end though, careful attention to detail and a thorough understanding of the conditions and chemistry involved in these analyses can help avoid problems before they occur or accelerate troubleshooting problems when they do appear. For this month’s installment of LC Troubleshooting, I invited Dr. Daniel Meston to share his short list of knowledge, tips, tricks, and advice related to analyzing peptides by LC–MS. There are many details that are important to consider in the preparation of samples and in the instrument prior to LC–MS data acquisition that can increase the likelihood of acquiring high quality data.

LC–MS has become the gold standard help users mitigate them and produce methodology used for proteomics, higher quality data in general.
which is the identification and quantification of protein abundances in biological samples. This is because of the ability of LC-MS to provide sensitive detection for untargeted peptides and identify unknown peptides through tandem MS (MS/MS) fragmentation and comparison of the experimental spectra to theoretical spectra prepared in silico. Subsequently, LC–MS-based proteomics tools have become invaluable in diverse disciplines ranging from immunology to microbiology and food chemistry. However, analysis of biomolecules is generally susceptible to a number of unique and perilous sample preparation pitfalls that can severely degrade the quality of data acquired, even when the most sophisticated LC–MS systems are used, which is because of the unique chemistry and size of large biological macromolecules, such as proteins, peptides, and oligonucleotides to name a few. In this installment, we provide our views on some of the most common pitfalls in sample and instrument preparation relevant to proteomic analyses by LC–MS. We hope that increasing awareness of these potential problems can help users mitigate them and produce higher quality data in general.

All mass spectrometric methods require the ionization of the analytes of interest before they can be separated and ultimately detected. For the peptides encountered in proteomic workflows, the ionization step is generally straightforward because conventional tryptic digestion of proteins often results in amino acid chains with terminal amino groups. Indeed, the protonation of peptides is so favorable that they are often observed as multiply charged positive ions. Given the ease of ionization of peptides, MS can almost be regarded as a “universal detector” for peptide analysis. However, this sensitivity can also be a double-edged sword in the sense that the detector will also respond to very low concentrations of easy-to-ionize contaminants in our samples, thus degrading the overall quality of the acquired data.

Polymers are perhaps the most frequently encountered type of contamination in proteomic samples, probably because they are present in most laboratories at levels high enough to matter to LC–MS work. A few examples of polymer sources include skin creams and moisturizing products, pipette tips, chemical wipes that contain an abundance of different polyethylene glycols (PEGs), and siliconized surfaces that contain polysiloxanes (PSs). The presence of these contaminants can be readily recognized in MS spectra by their characteristically large numbers of regularly spaced peaks in the spectra (44 Da spacing for PEG, 77 Da spacing for PS).

Another source of PEG contaminants is the use of surfactant-based cell lysis methods that are routinely employed in most molecular biology laboratories and involve surfactants such as Tween, Nonident P-40, and Triton X-100. Residual surfactant in samples that are produced using these chemical lysis methods have the potential to produce MS signals that can largely obscure the MS signal of the target peptides, thus rendering the data useless. A dramatic example of such a result is shown in Figure 1. When such protocols are used, extreme care should be taken to selectively remove the surfactants from the sample prior to analysis. Although it is certainly possible to remove PEG contaminants using solid-phase extraction (SPE), it is far easier in the long run to avoid the problem altogether and not use the surfactants for cell lysis in the first place.

In addition to problems with surfactants, urea used in cell lysis buffers can also cause problems. It is known that urea can decompose to isocyanic acid, which can in turn covalently modify free amine groups in peptides through carbamylation reactions (1). This chemical modification of the peptide can be accounted for in peptide identification software, but only if the software is instructed to look for this.

In general, residual salts can negatively impact chromatographic performance as well, and they can cause physical damage to fluidics and the MS-interface instrumentation by scratching the surfaces and clogging the emitter. As a result, residual salts should be removed from the sample prior to injection. Both urea and salts are most commonly removed using a reversed-phase (RP) clean-up step, such as SPE.

Not all high quality laboratory water is created equally, and there are many ways problems can arise with the water used for sample and mobile phase preparation. For example, in-line filters that are used to filter out deoxyribonucleic acid (DNA) can inadvertently lead to contamination of the water with PEG. Even the highest quality water produced on-site in the laboratory can begin to accumulate contaminants within a few days of production. Generally, we should avoid using water that has been sitting around for more than a few days after opening the bottle (if purchased) or production by a polishing system on-site. It is good practice to dedicate a specific subset of mobile phase bottles in the laboratory for LC–MS use only and to avoid washing them with any kind of detergent (2,3).

The most abundant protein contamination found in proteomic samples are the keratin proteins that make up our skin, hair, and fingernails. It is not uncommon to observe more than 25% of the peptide content of a proteomics sample to originate from keratin-derived peptides. Any steps that can be taken to reduce this type of contamination will improve the ability to detect low-abundant proteins of interest. In general, natural fiber clothing, such as wool, should not be worn in proteomics laboratories. Ideally, all sample preparation steps should be performed in a laminar flow hood to prevent dust and skin from the analyst and laboratory air from entering samples. Additionally, gloves should be worn at all times and replaced after touching a contaminated surface, such as stopwatches, pens, and laboratory notebooks. However, once the proteins have been digested, one should consider not wearing gloves because these can be a further source of polymer contamination.

Peptide adsorption to the LC columns has been addressed in previous installments of “LC Troubleshooting” (4). A lesser appreciated pitfall in proteomics sample preparation is adsorption of the peptides of interest to the vessel used for sample pretreatment (for example, digestion with trypsin), as well as LC sample vials. Peptides are multifunctional molecules with tremendous diversity in properties, including hydrophobicity and the number of acidic and basic functional groups.

These properties make them prone to adsorption onto materials with very different properties, such as glass and plastics. This observation is also true for proteins, but to an even greater degree (5). Adsorption of peptides from analytical samples onto such surfaces has been observed within timeframes as low as an hour after being placed in the LC vial, and they can result in a significant decrease in the apparent concentration of low-abundant peptides. A number of strategies to minimize sample adsorption to glass LC vials have been demonstrated, including the use of surfactants (which is not recommended for LC-MS, as discussed above). “Priming” vessels with a sacrificial protein, such as bovine serum albumin (BSA), is also done, similar to what is done with LC columns (4). The idea here is that the vessel is rinsed with a solution of a protein that is unrelated to the target proteins being analyzed (or synthetic peptides not found in biological samples); adsorption sites on the material are subsequently saturated and therefore unable to further adsorb peptides or proteins of interest from the analytical sample. Many vendors also offer “high-recovery” LC vials and other products that are engineered to minimize such undesirable analyte adsorption. An additional point to be aware of in this area is related to the removal of the sample solvent during the sample preparation process (for example, vacuum centrifugation to remove organic solvents). Completely removing all of the solvent promotes strong analyte adsorption onto surfaces; thus, it is helpful to avoid complete drying and to leave a small amount of liquid in the vial to increase analyte recovery.

Plastic micropipette tips present another opportunity to lose peptides to adsorption. With this in mind, it is important to limit the number of sample transfers during sample preparation, which has spurred the development of a number of so-called “one-pot” sample preparation methods that minimize contact between the sample and vessel, including nanoPOTS (6), SP3 (7), and FASP (8). From this research, it is becoming increasingly clear that single reactor vessel sample preparation protocols are superior to conventional protocols in the proteomics area.

Finally, when transferring peptide samples, it is best to avoid contact with metals. For example, most glass syringes are fitted with stainless steel needles by default. If a peptide sample is drawn up through a metal needle, peptides can be lost to adsorption on the metal surface. One way to avoid this scenario when using glass syringes is to remove the plunger, fill the sample into the glass syringe barrel using a glass pipette, and then push the sample out of the syringe using the plunger, but through a PEEK capillary fitted to the syringe via a Luer lock fitting, rather than pushing it through the metal needle. Doing so is particularly important in the case of MS calibrations where many vendors utilize a peptide calibrant that can be depleted by metal syringe needles.

Other aspects of the sample matrix are worthy of careful consideration. Although it is attractive to consider using trifluoroacetic acid (TFA) as a mobile-phase additive to improve chromatographic performance for peptides (that is, better peak shape, and increased retention, especially for hydrophilic peptides), this practice is generally frowned upon in the proteomics community because TFA can dramatically suppress peptide ionization, leading to lower overall detection sensitivity compared to using formic acid. An alternative to using TFA in the mobile phase is to add it to the sample and use formic acid to acidify the mobile phase. In this case, the TFA can enhance the retention of hydrophilic peptides on the precolumn, preventing them from eluting into the waste line. Meanwhile, the TFA exiting the precolumn is diverted to waste rather than entering the analytical column and MS interface.

Proteomics applications, which are outside conventional peptide sequencing, may also require specific buffers that preserve the structure or stability of proteins during analysis. It is not uncommon for these buffers to lead to salt precipitation on the electrospray emitter and the source cone of a MS system. In this way, one must optimize the conditions to use volatile buffers, such as ammonium acetate, or to physically clean the surfaces with water to prevent significant sensitivity loss. Recently, it has been demonstrated that post-column suppressor technology provides more flexibility in terms of the types of buffers that can be used, some of which are normally considered MS-incompatible (9).

Finally, the age of prepared mobile phases can be particularly problematic in proteomics applications where nano-flow systems are prevalent and mobile phase consumption is so low that a 100-mL batch of the mobile phase can last several weeks. Specifically, when buffer components with differing volatilities are mixed together, there can be selective evaporation of the more volatile component that will change the elution or ionic strength of the mobile phase, which can lead to changes in both absolute and relative peptide retention times. Primarily, this occurrence comes from incorrect viscosity values that change the mixing behavior of modern nanoLC instruments. Additionally, changes in ionic strength will have a direct effect on the retention factor of the analytes, which will lead to variation in retention time. As a rule of thumb, mobile phases should be replaced every 1–2 weeks to ensure reproducible results. Additionally, in the case of pumping systems that rely on known mobile phase viscosities for accurate flow rates, the mobile phase viscosity should be determined when changing solvents. Instruments that require this feature build in software routines to facilitate these measurements. An additional point is to consider not using conventional membrane degassers when using nano-flow rate because the flow rate is so slow during this process. It has been noted in our laboratory that volatile buffer components, such as formic acid, are preferentially removed from the mobile phase during degassing. In these situations, it is better to utilize alternative degassing measures, such as sonication, that have a low risk for additional contamination of the mobile phase.

Optimizing the Electrospray Source Voltages in nanoLC-ESI-MS

Finally, as we reach the last step prior to the actual acquisition of LC–MS data, we must think about settings for the MS detector itself. Arguably, one of the most consequential missed opportunities in data acquisition for proteomics workflows is related to the optimization of electrospray source voltages. Once analytes are ionized, they are steered through the MS instrument in the direction of the detector using carefully manipulated electric fields. Therefore, analyte detection is highly dependent on the voltage settings for the ion optics that guide the motion of the ionized analytes. Failure to optimize these voltages can result in peptides over large regions of the mass range not making it to the detector, or significantly reduced numbers of detected ions.

Before analyzing any experimental samples, it is worth taking the time to incrementally change the ion source parameters step-wise (for a representative ion infused at the flow rate that will be used in the LC–MS method, we recommend the doubly charged ion of Glu-Fib or angiotensin II), while monitoring the signal change and the spectrum quality. For most modern MS instruments, this tuning step can be done automatically within the MS data acquisition software, but it can be beneficial to further manually fine-tune parameters to maximize signal for the ions of interest. Finally, once the detector settings have been adjusted, it is a good idea to analyze a well-characterized quality control (QC) sample (for example, a cytochrome C digest or HeLa cell digest) to enable a final check on the data quality before analyzing any novel samples.

Because of the size and varied chemistry of peptides found in proteomics samples, it is important to pay attention to details of each step leading to the acquisition of LC–MS data. This includes sample preparation chemistries, sample handling, optimization of instrument parameters, and control of mobile phases. Paying attention to these details from the start can help avoid data quality problems entirely and simplify troubleshooting when problems do arise. We hope that the tips and tricks discussed here are food for thought for analysts of all levels of experience, and ultimately improve data quality and minimize loss of precious samples and instrument time because of unanticipated problems.

(1) S. Sun, J.-Y. Zhou, W. Yang, and H. Zhang,

(5) Y. Van Wanseele, K. Maes, K. Lanckmans, J. Van Schoors, I. Smolders, and A. Van Eeckhaut,

https://doi.org/10.1007/s10337-017-3397-9

(6) J. Woo, S.M. Williams, L.M. Markillie, S. Feng, C.-F. Tsai, V. Aguilera- Vazquez, et al.,

https://doi.org/10.1038/s41467-021-26514-2

(7) C.S. Hughes, S. Moggridge, T. Müller, P.H. Sorensen, G.B. Morin, and J. Krijgsveld,

https://doi.org/10.1038/s41596-018-0082-x

(8) J.R. Wiśniewski, A. Zougman, N. Nagaraj, and M. Mann,

(9) S. Wouters, I. Pijpers, N. Vanden Haute, D. Meston, L. Dillen, F. Cuyckens, and S. Eeltink,

https://doi.org/10.3389/frans.2022.1002935

Articles

Column: LC Troubleshooting

Knowing the tips and tricks of producing quality LC–MS data for peptide analysis can help streamline troubleshooting when problems occur.

Pitfalls in Proteomics: Avoiding Problems That Can Occur Before Data Acquisition Begins

In our September installment of “Sample Prep Perspectives,” we shared sample exam questions from our graduate Chromatography and Separations course as a refresher of some fundamental principles and to give readers the opportunity to test their knowledge. We’ve dusted off our files and found additional questions for this month’s column. These questions tend to focus on dealing with octanol-water partition coefficients, as well as more practical applications of sample preparation.

Question 1: Experimental measurements of K

 are not necessarily straightforward. Describe how you would go about measuring the
K

, or the octanol-water partition coefficient, is widely used to describe the
distribution of solutes in biochemical, environmental, and analytical systems
between nonpolar (lipophilic) and aqueous phases. It is defined as K

, though it is not simply the ratio of the solubility of the solute
(S) in the octanol and water phases. One must consider all equilibria occurring in the system, including the mutual solubility of the two solvents. Prior to making the determination of K

, the octanol and water phases must be brought into contact with each other, thoroughly mixed to obtain saturation of each solvent in the other, and allowed to separate into two separate phases in equilibrium. The solute of interest should then be added until saturation is reached, and equilibrium between the octanol and water phases is achieved. Mixing can help obtain equilibrium more quickly. Solute concentration in each phase can be measured via chromatography, spectroscopy, or other suitable means. Specific procedures for measuring K

 can be found in the methods of a number of regulatory and trade organizations.

Question 2: One common method for the extraction of fat from food samples is to use hexane. If you attempt to extract fat from foods using hexane in a microwave-assisted extractor, what will happen? Why?

Only materials with a dipole moment will absorb microwave radiation. As an overly generalized statement, a material's dipole will align with the electromagnetic radiation and oscillate with the frequency of the radiation. The resulting molecular vibrations release energy, which serves to heat the surrounding material. Hence, hexane, which is nonpolar, will not absorb microwave radiation. In this case, any microwave absorption, and subsequent heating, will occur because of any residual water in the food. If one wishes to perform microwave-assisted extraction (MAE) with nonpolar solvents, there are a couple general ways this can be done. Addition of a polar solvent to the extracting solvents can be used. However, considering the “like dissolves like” principle, convenient systems combining polar and nonpolar solvent are somewhat difficult to obtain. Most modern, commercial microwave-assisted extraction systems have an available “susceptor,” which will absorb the microwave irradiation and pass along the resulting heat via convection.

Question 3: Lipids samples, such as triglycerides, are generally hydrolyzed with an acid, then esterified to form fatty acid methyl esters (FAME), such as shown in equation 1 below, prior to analysis for total fats. The FAME are readily analyzed by gas chromatography–flame ionization detection (GC-FID). For example, this method is used for compliance with the Nutritional Labeling and Education Act, specifically in the food content labels we see in the United States.

Sucrose esters, such as shown in equation 2 below, are approved as fat substitutes when the R group is a fatty acid. Based on the chain length and saturation of the fatty acids used and the degree of esterification, the resulting sucrose ester will mimic a traditional lipid in terms of solubility properties, melting point, viscosity, and surface tension, among other traits.

Now, consider the situation of a food product that contains naturally occurring triglycerides, but is also processed with the sucrose ester. If acid hydrolysis and FAME analysis is used in the determination of lipids, the R groups in the sucrose ester would also be acid hydrolyzed, so the presence of the sucrose ester would give an artificially high value (such as a false positive) for the determination of triglycerides (analyzed as FAME). Suggest an extraction method with suitable selectivity to determine triglycerides in the presence of the sucrose ester.

This question can evaluate both an understanding of extraction selectivity and creative application of chemical knowledge. Because the properties of the sucrose ester are similar to traditional lipids, we cannot perform an extraction based on differential solubility. Perhaps the most common answer to this question is to perform some type of extraction which gets the FAME (and lipids) into the solution phase, followed by solid-phase extraction (SPE). This is certainly a promising method, and should work, though finding the appropriate combination of solvents and stationary phases is likely to take a great deal of research. Some students will suggest exclusion phases to perform the requisite separation of triglyceride from sucrose ester. Other forms of solvent extraction, such as pressurized solvent extraction (PSE), with the sorbent material added to the extraction vessel, may expedite the extraction, though the added effect of the heat may make obtaining suitable selectivity challenging.

The next most promising method would be supercritical fluid extraction. By manipulation of the applied temperature and pressure, one should reasonably expect to separate various classes of lipids, including the sucrose esters, from each other.

The method which was developed by the industrial creator of the sucrose ester (1) relies on the traditional method, with the exception that the hydrolysis step is performed with lipase. These enzymes offer selectivity as they look for the three-carbon glycerol back- bone of mono-, di-, and triglycerides, and will not recognize the sugar backbone of the sucrose ester (the same principle by which the sucrose esters are “fat free”).

To one trained in biochemistry or food science, this approach may seem straightforward. However, to many analysts, this approach requires some critical understanding of the chemistry of the system being studied, as well as out of the box thinking since this type of approach is not found in traditional analytical training.

Question 4: The Environmental Protection Agency (EPA) method 625 (2) is used for the determination of bases, neutrals, and acids in drinking water and wastewater via liquid–liquid extraction (LLE) of 1000 mL of sample. A solid-phase extraction alternative (3) has been developed that uses 100 mL of sample, significantly less solvent, and gives better analyte recovery. Table I provides a method results summary for spiked synthetic wastewater.

Discuss the advantages and disadvantages of SPE compared with LLE for this extraction.

For this question, we can assume that the student has not reviewed the application note with the new method or the EPA method, though this assumption may be incorrect for a take-home or similar exam. Based strictly on the information presented in the table (and devoid of other potentially relevant information), evaluation of the sample size indicates that the disk format of SPE must have been used. SPE cartridges are typically used of sample sizes smaller than tens of milliliters. Compared with LLE using samples of similar size (1000 mL), the SPE disk approach is approximately 1.3–1.7 times faster, and uses approximately 45% less solvent. With less solvent use, there is an associated green advantage of less waste, lower flammability hazard, and less use of potentially toxic solvents. Also, less solvent means lower cost and faster solvent evaporation steps. SPE does not deal with emulsion formation problems. Standard deviations are not shown, so we cannot comment on the reproducibility of the methods shown. Whether LLE or SPE is superior in terms of analyte recovery from one-liter samples is unclear. The recoveries shown, lower than the recoveries with SPE of a 100-mL sample, may be because of the difficulties of handling one-liter samples. However, closer inspection reveals that the recovery may be related to analyte acidity, so use of a mixed-mode SPE phase, perhaps by combining two or more disks, may improve the recovery via SPE. Use of 100-mL samples with SPE demonstrates several interesting features. First, the recoveries are consistently higher across all analyte types, indicating that perhaps the sorbent loading of the disks is more appropriate for the smaller samples. Another consideration is that, with the 100-mL samples and SPE, the ratio of solvent eluent volume to sample amount (0.8) is much larger than with the 1000-mL samples (0.2 for SPE and 0.36 for LLE). This increase in the relative amount of solvent used may explain the further reduction in extraction time and increased recoveries.

Question 5: Figure 1 (4) shows that, everything else being equal, stir-bar sorptive extraction (SBSE) can extract more solute (of equal K

) than solid-phase microextraction (SPME), and that solutes with a K

 too low to be quantitatively extracted with SPME may be effectively extracted with the SBSE method. Explain why this is.

The stir bars used for SBSE have a much larger surface area than the fibers used in SPME. Consequently, they contain on the order of 50–250 times more extracting phase (sorbent). With such an advantage in terms of phase ratio, SBSE is expected to expected to separate various classes of solute with lower K

 and greater amounts of solutes with similar K

However, this advantage of greater amount of solute extraction comes at a price. Both the sorption and desorption steps in SBSE are significantly slower than in SPME, though automation may help address the sorption and desorption steps. Although other practitioners may disagree, I contend that SPME is preferred when gas chromatography is the subsequent analysis step, and SBSE is preferred when liquid chromatography is used (though either approach can be used for any type of chromatography). However, as a result of this bias, it is important to remember that, with biological samples, macromolecules like sugars and proteins may need to be washed from the sorbent phase in SBSE, while this is less likely the case in SPME. Both SPME and SBSE are non-exhaustive equilibrium-based extractions, meaning that calibrations must be determined during the method development phase to determine the extraction duration to achieve equilibrium. Finally, it should be noted that newer configurations of SPME, such as the SPME-Arrow, have increased sorbent amounts, though still less than found in SBSE.

Question 6: Consider an ionic compound, MX, composed of the cation M

, which dissociates in water. Write the equilibrium equation for each equilibria in an extraction system.

Consider an organic extracting phase (org) and an aqueous sample phase (aq). The equilibria between each species in each phase must be considered:

Depending on the dissociation constant of MX(aq) and the sizes of the relevant equilibria constants, it is likely that only equilibria 2 and 3, and perhaps 1, will be important in an analytical extraction. For some polyatomic systems like the bicarbonate-carbonate system, all dissociations:

I hope these exam questions over the past couple of columns has been fun and educational. I enjoyed putting them together. Now, with our next installment, we’ll return to more focused treatments of specific sample preparation techniques and applications.

(1) D. Schul, D. Tallmadge, D. Burress, D. Ewald, B. Berger, and D. Henry.

(3) W.R. Jones, A. Cannon, D. Gallagher, M. Ebitson, and Z. Grossner,

http://www.chromatographyonline.com/new-method-us-epa-625-solid-phase-extraction-challenging-wastewaters

(4) F. David, B. Tienpont, and P. Sandra,

Column: Sample Prep Perspectives

Test your knowledge of octanol-water partition coefficients and practical applications of sample preparation.

Class Is Back in Session: More Questions on Your Extraction Knowledge

The electron capture detector (ECD) is among the original classical detectors for gas chromatography (GC). It is highly selective and sensitive for electron-absorbing compounds, especially those containing halogens. The ECD was developed in the 1960s by James Lovelock (1919–2022), who passed away earlier this year. The ECD is among the early detectors that is used in a relatively unmodified form today. The ECD was crucial in the discovery of chlorofluorocarbons (CFCs) in the upper atmosphere, ultimately leading to the international agreements limiting their use and reducing the ozone hole. In this installment, we review the ECD and its principles of operation and discuss the general tradeoffs in detection between selectivity, ease of use, and sensitivity. We also look at the unique life and work of Lovelock, both inventor of the ECD and one of the earliest scientists to bring attention to climate change through GAIA, which explained his theory that the Earth acts as a massive living organism.

This summer, I was watching the news show “Sunday Today,” and heard a name familiar to many gas chromatographers: James Lovelock. To chromatographers, Lovelock invented the electron capture detector (ECD) for gas chromatography (GC). He was featured in the weekly “Life Well Lived” segment, where the show features people who are not widely known to the public but made contributions to public life (1). The segment describes how the ECD and Lovelock’s own work provided major influences on climate science today, nearly 60 years later.

Detection in GC remains unique in analytical chemistry because of the large number of customized detectors. For early workers, detection was especially challenging because the detector was required to be sensitive, selective, and able to detect a low concentration or mass of analytes in a rapidly moving stream of carrier gas. Interestingly, many of these early detectors, including flame ionization detectors (FIDs), thermal conductivity detectors (TCDs), and ECDs remain widely used today, along with myriad additional ionization, physical property, and spectrometric detectors. Schug and McNair provided a summary and “grade sheet” for commonly used GC detectors (2). The ECD was graded A+ for limit of detection (LOD) and specificity, but it was given a C grade for qualitative speciation, linear range, and robustness, and a D grade for universal response.

A summary of the basic principles and operation for the ECD is provided in textbooks on GC and available in ChromAcademy,

’s online learning platform (3–5). Overall, the ECD provides a unique combination of selectivity and sensitivity. Implied by its name, the ECD offers selectivity for compounds that include atoms that are favorable for attracting or capturing an electron. Recalling general chemistry, note that elements on the right and up in the Periodic Table tend to attract electrons. These include the most common heteroatoms, especially halogens. The ECD is highly selective for compounds containing these elements, and by contrast, generates little or no signal for common hydrocarbons. The ECD presents a useful complement and contrast to the FID, which gives strong signals for hydrocarbons.

Highly selective detectors, in general, offer greater sensitivity for those analytes for which they are selective. The ECD is noted to be the most sensitive of the classical detectors, with detection limits easily in the part- per-billion (ppb) concentration or picogram mass range. Finally, highly sensitive detectors, including the ECD, have very specific requirements for obtaining the expected high sensitivity. In the case of the ECD, the carrier and makeup gases must have scrupulous high purity, samples should be especially clean, and the operating environment should be free of contaminants containing electron absorbing atoms. Together, these operational factors lead to the grades shown for the ECD by Schug and McNair.

Figure 1 shows a schematic diagram of a typical ECD. The operating principle, while not fully understood, first involves the production of electrons from a radioactive source, typically

Ni. For safety, a sealed source is used and usually the detector manufacturer will have a blanket radioactive isotope license in case the end user does not. Radioisotope licensing was an early barrier for ECD users. If you ever need to dispose of an ECD, you should consult with the manufacturer, a licensed health physicist, or radiation safety officer for proper disposal procedures.

Unique among ionization detectors, the ECD measures a reduction in the electrical current rather than production of a current. Electrons produced in the radioactive source ionize carrier gas, usually nitrogen, molecules flowing through the detector cell. If the carrier gas is helium or hydrogen, nitrogen makeup gas is used. Electrons produced by the ionized nitrogen migrate to the anode under a fixed voltage, generating a steady electrical current. If electron-absorbing species pass into the detector cell, they absorb electrons, resulting in a reduction in the standing current.

Figure 2 shows an early example of ECD selectivity from Lovelock’s original work in 1960 (6). The top chromatogram shows the separation of eight compounds using a classical argon detector (not commonly used today). The bottom chromatogram shows the separation of the same eight compounds using the ECD. Note the stronger argon detector signals for the hydrocarbon and fluorinated compound, for the singly-chlorinated benzene, and the strong ECD signals for the multiply chlorinated compounds.

In 2007, Ettre and Morris provided a thorough discussion “The Saga of the Electron Capture Detector” in

 (7). They trace the developments that led to the ECD beginning in 1948, showing a fascinating scientific story that began with studying a different problem (whether drafts of cold air in a room really do cause illnesses) for which Lovelock developed an anemometer that worked by disturbing the slow flow of positive ions from a radon source. This anemometer was so sensitive that the signal was disturbed by small amounts of cigarette smoke in the atmosphere, capturing electrons, although at the time this was seen as a problem and not of any interest. Recall that smoking was much more prevalent in the 1950s than it is today. In my own career working with modern ECDs, I have observed deflections in ECD signals because of the presence of cigarette smoke odors. The full story, presented by Ettre and Morris, of how this observation ultimately led to today’s ECD is well worth the read.

The Science Museum of London also has an early ECD and other equipment, including Lovelock’s own home-made gas chromatograph on display and an extensive treatment of Lovelock’s life and career, along with Lovelock’s entire personal archive of documents and letters (8).

Lovelock, Atmospheric Chemistry, and GAIA

Lovelock’s prolific scientific career, spanning seven decades, included many more contributions than inventing the ECD for use in GC. As with many of the early gas chromatographers, his career started in other areas. His first publication in 1941 related to the use of hypochlorite spraying for disinfectants (9). Then, he had a prolific publication record in the general area of disinfectants, sports training, prevention of the common cold, and other medical topics through the remainder of the 1940s and early 1950s. After earning his PhD in medicine in 1948, a shift toward instrumentation and measuring devices was seen throughout the 1950s. Through the 1950s, his medical research shifted to many aspects of preservation and chemical effects on red blood cells and some interestingly titled articles related to the re-animation of rats and mice frozen to 0 °C.

As Ettre and Martin describe, in the 1950s, Lovelock’s laboratory was in close proximity to A.J.P Martin and A.T. James, who invented GC and they became collaborators, with Martin suggesting to Lovelock that he develop a highly sensitive detector that was operable by average chemists. They noted that the most sensitive detectors of the day were not easily operated by most chemists. The first mention of GC in the title of an article written by Lovelock occurred in 1958. In the article, he discussed an early detector, not the ECD but the argon ionization detector, which like the ECD used a radioactive source to produce electrons that ultimately ionized analytes. It was a nearly universal detector, used for many applications that were ultimately supplanted by the FID, which did not require a radioactive source (10). Using the argon ionization detector, Lovelock then published numerous papers on the ionization mechanisms of organic compounds in the vapor phase, most often using GC with the argon ionization detector.

Following the initial invention and publication of the ECD (6), Lovelock worked with Zlatkis to commercialize the detector, founding a company called Ionics Research, which provided ECDs to PerkinElmer and the Wilkens Instrument and Research Company, which later became the Chromatography Division of Varian bought in 2010 by Agilent Technologies. In 1962, coincidentally with the publication of the classic book

 by Rachel Carson, the first papers demonstrating ECD of pesticides at the picogram level were being published; although, as pointed out by Ettre and Morris, the ECD is often incorrectly cited, including in the “Sunday Today” segment, as one of the techniques on which Carson’s findings were based (11). However, there is clear connection between Lovelock’s work, the ECD, the early environmental movement, and today’s challenges with climate change.

Using the ECD, Lovelock published the first work demonstrating the presence of chlorofluorocarbons (CFCs) in the atmosphere over the Atlantic Ocean between England and Antarctica (12). This work demonstrated the presence of Freon-11 and other compounds resulting from the use of aerosol cans and refrigerants. Roland and Molina then used this work in developing the theory that halocarbons in the atmosphere were reacting with stratospheric ozone in a chain reaction, causing the depletion of ozone and the famous “ozone hole” (13). Roland, Molina, and Crutzen shared the Nobel Prize in 1995, and this work resulted in international treaties limiting the use of halocarbons.

We close with GAIA, a fundamental aspect of climate science today, that was mocked by most when introduced by Lovelock in the 1970s. Much like the seeming lack of interest in the 1950s in a detector that was affected by cigarette smoke in the room, GAIA, named for the Greek goddess of the personification of Earth, proposed that the Earth is a single self-sustaining organism, and this idea was universally rejected by the scientific community of the day (14). The basic principles and problems described by Lovelock in his original work remain debated in climate discussions today. With the invention of the ECD, its use in discovering CFCs in the atmosphere, work in planetary, medical, space and climate science, James Lovelock was not just a chromatographer but a true Renaissance man of science.

https://www.today.com/video/dr-james- lovelock-scientist-who-created-gaia-theory-dies-at-103-145164869912

(3) H.M. McNair, J.M. Miller, and N.H. Snow,

 (John Wiley and Sons, Hoboken, NJ, 2019), pp. 131–134.

 (Elsevier, Amsterdam, The Netherlands, 2nd ed., 2021), pp. 343–358.

https://www.chromacademy.com/channels/gc-training-courses/instrumentation/gc-detectors/

Something in the Air: James Lovelock and Atmospheric Pollution

https://www.sciencemuseum.org.uk/ objects-and-stories/chemistry/something-air-james-lovelock-and-atmospheric-pollution

(12) J.E. Lovelock, R.J. Maggs, and R.J. Waade,

 (Oxford University Press, Oxford, United Kingdom, 1979).

Column: GC Connections

The electron capture detector (ECD) for GC is still used relatively unmodified today. But using it effectively means understanding the tradeoffs between selectivity, ease of use, and sensitivity.

Selectivity and Sensitivity: The Electron Capture Detector (ECD), Its Unique Inventor James Lovelock (1919–2022), and GAIA

The landscape of biopharmaceutical analysis features different analytical requirements in terms of instrumentation and type of analysis (QC, RTRT, and in-process). One of the questions that often crops up for routine analysis is “How much replication is enough?” Should all the samples be run in triplicate irrespective of the type of analysis, or does the type of analysis (such as charge or size variants) have any bearing on the number of optimal replicates?

There are various factors that the user needs to consider in the matter of biopharmaceutical analysis—first, the objective of replication, and second, the trade-off with respect to cost and time. Ideally, the number of replicates should be large enough to adequately represent the variability present, but not so large that the information gained is unjustifiably expensive with respect to the costs (such as instrument time, analyst time, consumables, and samples). The optimal replication applicable to each type of analysis would therefore lie somewhere in between. For any given sample, one must also consider the sources of variability at play. Although some of these sources would be generally applicable to all types of analytical assessments (including analyst-dependent and system-dependent variabilities), some may be unique to the dynamics of a specific biomolecule, such as changes occurring during analysis (stability related). Traditional data accumulated for a specific analysis and molecule over time can help understand and evaluate effective replication numbers.

In this article, we use data generated in our laboratory for a published biosimilarity exercise on marketed trastuzumab biosimilars in order to understand and illustrate how the optimum replication number might be influenced by a) the analysis type; and b) devised strategies for efficient utilization of resources to estimate replication number for a given analysis type (Figure 1) (1).

Blocking and randomization are used in statistical experimental design to balance variability and measure size. After calibrating the equipment and validating the method to reduce variation due to nuisance variables, replication is required to increase the experiment’s informative power. The size of the experiment can be influenced by increasing or decreasing the number of replicates (2).

Increased replication helps to reduce the standard error, which is a measure of the magnitude of the experimental error of an estimated statistic. In contrast to the standard deviation, which relates to the inherent variety of observations within individual experimental units, the standard error refers to random fluctuations of a total estimate. By increasing replication, the standard error can be made arbitrarily small. This implies we want a standard error that is small enough to draw reasonable inferences, but not too small.

 is when you declare an effect to be real, and, in reality, it is zero. Setting this to a certain value is usually represented by selecting a value for

 limits this kind of error to a related percentage of probability. Therefore, type I error is also sometimes called

 error, which will be discussed in the following section, is regarded as

It bears mentioning that simply protecting against type I errors may not be sufficient. Samples of sufficient size may nearly ensure statistical significance, regardless of how little the difference is, as long as it is non-zero. Assuming we only want to discover differences that are important in practice, we add an extra precaution against a type I error by avoiding employing sample sizes greater than those required to defend against the second kind of error—the so-called type II error.

Type II errors occur when an effect is genuine, but is neglected. When the replicates vary slightly, such a failure may not be significant. Only when the disparity is significant does it become problematic. The second step is specifying the probability of actually detecting it. This probability (1-β) is called the power of the test. The quantity β is the probability of failing to detect the specified difference to be statistically significant, and therefore this error is also sometimes called a

Mathematically, the size of the experiment depends on the estimate of variance (σ

); the true difference (δ) that we are set out to detect; the effect of assurance with which it is desired to detect the difference (the power of the test); the significance level that will be utilized in the experiment; and the type of test being necessary (as in whether a one-tail or two-tail test). The required sample size,

By rearranging equation 1, we can get the true difference, δ, in terms of size

 are the type I and type II errors, respectively, the values for which can be found in the

 tables from most standard books on statistics (see Table I).

In the following, we illustrate this approach using examples from three routine analytical techniques used in biopharmaceutical analysis—namely, Fourier transform infrared spectroscopy (FT-IR), cation exchange (CEX) chromatography, and fluorescence spectroscopy (FLR). For each of these methods, the considered readings were taken in respective region of interests (ROIs) while estimating the variance, and the final estimate was made by averaging the obtained variances for replicates in each batch for all the originator and biosimilars being considered here in this study. For FT-IR, the original data measured over 400–4000 cm

. In CEX, the readings were over 0–20 min; the considered ROI is 9–17 min. In the fluorescence data, the ROI was taken in just the Gaussian curve, and it was between 310–370 nanometers. After estimating the averaged variances, we can find the relation of how the δ changes with the replicate number. Here, we study two confidence intervals of 95% and 99% for each of the errors.

With the Z values and estimate of the variances, we can obtain a curve for δ versus the replication number (Figure 2). Starting with FT-IR data (Figure 2a), we obtained an average variance of 7.052e

 in the observed ROI. This helps us visualize the increase in the impact of higher replication on the ability of capture differences between the given data sets. Similarly, the observed variances (averaged) in CEX (Figure 2b) and fluorescence (Figure 2c) data were 117.088 and 77.153, respectively, for the considered ROIs in each. As the relationship between the two axes is the same (inverse root of replication), the order of values on the vertical axes corresponds to the order of response measured for the experiments, from which the variances were calculated and averaged. The effect of increasing the power of errors (moving from 95% confidence to 99% confidence) reflects an upwards shift of the curve along the

-axis, implying that the overall trend of the curve remains the same, and that the true difference that could be captured is more at each particular replication number.

The relationship between delta and replication is non-linear and exponential in nature, meaning that, beyond a certain number of replicates (thereafter referred to as optimum replication

), the cost associated with replication is greater than that of the value of the information gained. It would then help to have a mechanism to decipher the value of

 for a given analyses. To achieve this, we need methods that inherently consider the estimated variance and the power of tests used.

While estimating an optimum, it is important that the devised methods capture the effect of the estimated variance for the different data sets, and yield a number accordingly. For example,

 may differ among the different chromatographic and spectroscopic techniques. Keeping this in mind, we explored three approaches to yield an estimate for

. The methods essentially exploit the shape of the curve obtained as a function of the relationship between delta and replication number, and are based on exploration of geometrical features (such as slope, center, and deviation from linear relation). We have applied this to three types of data sets commonly obtained in biopharmaceutical analysis—ion exchange chromatography, FT-IR spectroscopy, and fluorescence spectroscopy.

Physically, the replicate number will be integral, and equation 1 should yield discrete values as the number goes from 1 to 10 (10 has been defined as a maximum here based on general laboratory practices). However, to leverage the curve mathematically, we have considered it to be continuous for this and the subsequent estimation below.

In the slope method, we first look at the overall decrease in the variance over the maximum replication that we could go to (defined here as 10). In graphic depiction, this number corresponds to the line AB in Figure 3a. The plots considered here are for the fluorescence data at 5% significance and 95% power for type I and II errors, respectively.

With that line, we find the point on the replicate axis that has a slope equal to that of line AB; one can easily argue that there would indeed exist such a point. Using equation 2, upon differentiating, we get a mathematical expression for the slope in continuous domain as:

Using equation 3, we compare the slopes at each point, and get a number having the same overall decrease of detectable delta over replicate. We plot the difference between the slopes to visualize the trend, and then the minima of it. As depicted in Figure 3b, the minima is found to be at 3.514. Graphically, we will have a tangent with an equal slope as that of AB, as shown in the Figure 3c.

Because we are working in the continuous domain, we will get a positive real number as the estimate that needs to be rounded off to the closest integer for physical consideration. Having done that, we have estimated a number that we can say to be optimum. Here, the closest integral number to 3.514 will be 4, so that is our predicted optimum.

This method of slopes is based upon finding the maximum deviation of the delta values, if the relation was to be linear between them and the replicates with a slope the same as that of a line joining the end points of our considered replication range. It can also be said to be looking at the maximum dip present graphically, as depicted in Figure 4a. The deviation distances should naturally go to a maximum value as it is zero at both ends of the curve.

Thus, the continuous deviation values can be plotted, as shown in Figure 4b. Mathematically, it so happens that the numerical optimization function becomes the same upon differentiating while maximizing the deviation distance, resulting in an expression identical to that obtained when the slope was compared. This is basically because of the nature of the function that we are using. The summary of the estimated optimum is as given in Table II.

We see that the predicted optimum number using this method is the same for all spectroscopic methods, thus essentially suggesting that this method has failed to recognize the variance in it, and it predicts a generalized

Through this approach, we find the center of the curve (the point on the curve that is equidistant from both the ends of the curve). As the point being equidistant from the two extreme ends (as in Figure 5a) are competing with the detectable difference and the replication done, the middle point can be an optimum balancing the two conflicting aspects of the features of the curve.

We plot the difference of the distance of the points on the curve and expect a minimum to be there, highlighting the point that is equidistant. Figure 5b shows the variation of the difference of distances for points on the curve from the ends. The minima occur at 2.829. By rounding off, the integral estimate that we get is 3. Graphically, we see that the point of the minima subtends equal angle with the line AB, and will essentially make an isosceles triangle, including itself and the triangle PAB, with PA and PB being the two equal sides (Figure 5a). The summary of the results obtained using this method is shown in Table III.

Therefore, we see that each method yields a unique number based on the variance obtained from the respective technique for a given analysis, providing an appropriate method to make an estimation.

Having seen a couple of methods based on using geometrical aspects of the curve, we now try to develop a cost function that penalizes if the replication number is too high, and incentivizes for the low delta values, so that we anticipate a minimum in the function as we increase replication.

Initially, we proposed a function as equation 4. As

 increases, the function value increases. However, at the same time, because of the corresponding decrease of delta values, the function value decreases as well.

Considering this, we can expect a minimum value, but that minima can possibly fall well above our maximum number of replicates taken. This function being explicit in terms of replicate number, upon solving this function mathematically, we get the

We see here that optimum is dependent on the variance that is essentially desired, but the order of variance can be very different for experiments. To handle this uncertainty, we can further modify our function by dividing δ by σmin, where σmin is the lowest variance observed of all the previous experiments; for fluorescence data, the observed minimum in the data set was 48.472. The function then can be written as equation 6:

Mathematically, the optimum for this function can be written to be at:

Although we have a mathematical expression, we plot the function and try to depict the minima that must be there. Figure 6 shows the plot of the cost function for fluorescence data (at 5% significance for α, and 95% power for β). We can see that the minimum is in our limit to our maximum range. The summary of the results obtained using this method are presented in Table IV.

Here again, we get a unique number for each experiment, thus being a consistent approach to estimate an optimum with.

Irrespective of the analysis, the general scheme to be followed for

 estimation is shown in Figure 7, starting from the raw data to the proposed approaches.

 estimation approaches can be compared based on effect and the range of relation they share with the estimated variance of a given technique and analysis type, it being the defining feature for the relevance of

 obtained. While the first approach is insensitive to estimated variance, it could be used as an estimation method where the innate mathematics inherently incorporates the impact of variance (and other such related parameters) over the estimation.

The second approach, while being sensitive to individual technique vari- ance, does not measurably distinguish between confidence for both type I and II errors, as can be seen in Table III.

The last approach based on the developed cost function is both sensitive to technique specific variance as well as the error confidence interval, and thus can be applied across analytical characterization platforms to get a realistic and relevant understanding of the replication required, which is technique and analysis specific based on variances derived from existing analytical data, thus facilitating a more rational approach to defining replication.

Although the work discussed here is in specific context of biopharmaceutical analysis, it would be equally applicable across different domains where chemical data is generated in the form of

 (CRC Press, Boca Raton, FL, 2nd ed., 2002).

(3) A. Banerjee, U.B. Chitnis, S.L. Jadhav, J.S. Bhawalkar, and S. Chaudhury,

(5) J. Charan, R. Kaur, P. Bhardwaj, K. Singh, S.R. Ambwani, and S. Misra,

Column: Focus on Biopharmaceutical Analysis

What is the right number of replicates in biopharmaceutical analysis?
Does the answer depend on the type of analysis?


On Replication in Biopharmaceutical Analysis

Per- and polyfluoralkyl substances (PFAS) continue to need novel analytical tools for their proper characterization. Regulatory bodies are lowering the acceptable concentrations for contaminated matrices, requiring state-of-the-art instrumentation to detect sub-ng/L levels. Suspect screening (for known PFAS without certified analytical standards) is becoming more popular as the list of known PFAS grows to thousands of compounds. The methods that currently exist for suspect screening require updating to move them from boutique, study-by-study methods to those that can be adopted more universally to generate transferable data sets. Some of those updates are presented here with the hope that they are adopted by laboratories in industry, government, and academia.

Per- and polyfluoroalkyl substances (PFAS) are a class of compounds characterized by the presence of highly inert carbon–fluorine bonds that impart both oleophobic and hydrophobic properties. These properties have made PFAS useful ingredients in a variety of manufacturing processes, including food packaging, papers and textiles, industrial nonstick coatings, and aqueous film-forming foams (AFFFs) for extinguishing hydrocarbon-based fuel fires. These compounds are sometimes called “forever chemicals,” because they do not break down readily in the environment and those that do (precursors) degrade to more stable end products. The U.S. Environmental Protection Agency (EPA) published a strategic roadmap in 2021 outlining plans to deal with PFAS contamination (1).

The world of PFAS is an exciting avenue of exploration for analytical chemists, because advanced studies involving fate and transport in the environment, ecotoxicity, and treatment can be performed. However, fundamental questions about the detection, quantification, and communication of PFAS results still need to be answered. These challenges bring together separations science, mass spectrometry (MS), data science, environmental engineering, and even public policy.

What constitutes a PFAS molecule has been an ongoing debate. Common among definitions is the presence of a carbon–fluorine bond. However, many molecules can contain a single carbon–fluorine bond and would not be considered PFAS. The main definitions have been built into the PubChem Classification Browser (2), where analysts can generate lists of PFAS according to each definition. Various lists of PFAS have been curated; as a result, there is a lack of consensus because of the varying definitions across lists. The list we chose to use in our studies is one curated by the National Institute of Standards and Technology (NIST) of the United States (3). All lists contain varying amounts of data for each entry, with each having at least the molecular formula. The NIST list contains the molecular structure in a machine-readable format (international chemical identifier [InChI] in this case), and this structure becomes the identifier for each compound. Acronyms and the International Union of Pure and Applied Chemistry (IUPAC) names have been inconsistent across lists; InChIs are a way to unify communication of the results (4). The conversion of InChI keys to draw molecular structures presents an approachable and time-saving exercise in computer coding for the intrepid chemist.

MS has been the choice detector, coupled with gas chromatography (GC) or liquid chromatography (LC), for volatile or non-volatile PFAS analysis, respectively. Most PFAS receiving regulatory scrutiny have been non-volatile, and LC– MS has been the most often used tool.

Targeted analysis of PFAS is done using triple-quadrupole detectors to monitor ion transitions for quantification. The availability of analytical standards has increased greatly over the past 20 years, from almost no standards to mixes where dozens of PFAS can be included in a targeted run. Not all native standards have an exact-matched isotopically labeled surrogate, so some surrogates are borrowed by natives within a PFAS class. It is best to avoid recruiting surrogates from natives where high concentrations are expected. High concentrations will suppress the surrogate signal, which is fine for the exact-matched native but not for a native borrowing the surrogate. For low concentrations, advances in instrumentation and preconcentration steps have led to sub-ng/L levels of detection (LOD) for certain PFAS. Such low levels make contamination an issue not to be underestimated, even in routine targeted analysis.

After targeted analysis, suspect screening and non-targeted analysis are the next frontier in PFAS identification. Suspect screening requires the use of a high-resolution detector, such as a quadrupole time-of-flight (QTOF), ion mobility (IMS), or an orbital trap MS instrument. Mass-to-charge (

) ratios are screened against a list of PFAS to look for similar masses. Then, confidence in the identified compound is increased through isotope ratio differences, the presence of diagnostic fragments, and other data acquired. These confidence levels were initially communicated using the scale developed by Schymanski and others for all non-targeted MS work (5). This scale was the framework for a new scale that our team created to communicate confidence of PFAS identification using features specific to PFAS (6).

The growth in awareness of the true number of PFAS has far outpaced the availability of analytical standards for true quantitative analysis. The demand for PFAS research led to the idea of reporting new or suspected compounds in a semi-quantitative way. Most new or suspected PFAS are either part of an existing homologous series, or have only small changes to headgroups. For new or suspected PFAS, one would borrow the calibration curve from a similar compound that does have an analytical standard, assume an equal molar response by the detector, adjust for molar mass differences, and call this a semi-quantitative concentration. This technique assumes that the ionization efficiencies between the suspect PFAS and the borrowed calibration PFAS are similar. Although this strategy worked initially, a number of problems have been found over time. The discovery of new PFAS compounds has outpaced the ability to match them to existing standards.

As studies have become more complex, involving multiple environmental matrices with vastly different PFAS concentrations, the matching had to be altered for different matrices. Different matching schemes are used across the literature, making comparisons across studies difficult. Finally, different laboratories run slightly different analyte lists, making a universal matching scheme unattainable. To address this, we developed a new method to estimate concentrations that we believe can accommodate the rapid growth in demand for PFAS testing and information.

The PFAS curve replaces one-to-one matching with a single, average curve comprising all the PFAS standards run in a particular study (Figure 1). The same curve is used for all suspected PFAS, including non-targeted PFAS where the exact structure and location of functional groups (and thus estimated ionization efficiency) may not be known. This technique was partially inspired by an idea from data censoring, where traditional techniques, such as substitution of values below the limits of quantification (LOQ), presented a false sense of knowledge about the data (7). In the case of one-to-one matching, ionization efficiencies of suspect compounds can only be known using analytical standards, and without those, the ionization efficiencies are an educated guess at best. The single PFAS curve is likely wrong for most suspects, but it is wrong systematically, and if multiple studies use this technique, the estimated concentrations are comparable across data sets. Finally, it is a computationally simple approach compared to one-to-one matching and has a better chance of being adopted by laboratories across government, academia, andindustry. We are currently working on a study using

F-NMR to measure the total organic fluorine to quantify the variability of this method.

The details of naming and quantifying PFAS are important when the scale of PFAS contamination is realized. A recent study proposed that most rainwater, even in remote areas, contained PFAS above the health advisory levels set by the U.S. EPA (8). Solutions to this problem will require new thinking and incorporating new methods of data analysis, such as machine learning. The more data can be generated and shared, the better these problems and solutions can be understood. Some of the techniques outlined here should help in streamlining and automating much of that work.

The author would like to thank the Strategic Environmental Research and Development Program (SERDP) for funding through grants ER19-1205 and ER20-1375.

PFAS Strategic Roadmap: EPA’s Commitments to Action 2021-2024

 (U.S. Environmental Protection Agency, Washington, D.C., EPA Report EPA-100-K-21-002, 2021).

(2) National Center for Biotechnology Information,

https://pubchem.ncbi.nlm.nih.gov/classification/#hid=120

Suspect List of Possible Perand Polyfluoroalkyl Substances (PFAS), National Institute of Standards and Technology

(4) S.R. Heller, A. McNaught, I. Pletnev, S. Stein, and E. Tchekhovskoi,

https://doi.org/10.1186/s13321-015-0068-4

(5) E.L Schymanski, J. Jeon, R. Gulde, K. Fenner, M. Ruff, H.P. Singer, and J. Hollender,

https://pubs.acs.org/doi/pdf/10.1021/es5002105

(6) J.A. Charbonnet, C.A. McDonough, F. Xiao, T. Schwichtenberg, D. Cao, S. Kaserzon, et al,

https://pubs.acs.org/doi/10.1021/acs.estlett.2c00206

Statistics for Censored Environmental Data Using Minitab and R

 (John Wiley & Sons, Hoboken, NJ, 2nd ed., 2012).

(8) I.T. Cousins, J.H. Johansson, M.E. Salter, B. Sha, and M. Scheringer,

https://pubs.acs.org/doi/pdf/10.1021/acs.est.2c02765

Columns

With suspect PFAS screening becoming more popular, and the list of known PFAS now in the thousands, novel analytical tools are needed to generate transferable data sets. We highlight key updates here.

Tools for Investigating the Expanding Per- and Polyfluoroalkyl Substances (PFAS) Universe

Integrating electric fields into extraction techniques increases sensitivity and selectivity. These approaches are compatible with miniaturized, portable, and many biological samples.

Extraction-based sample preparation has been recognized as a significant step in separation science. To improve the sensitivity and selectivity of the extraction, some new approaches have been introduced, including those that employ an electric field. These electric field–assisted extraction methods create another dimension for sample preparation, and are compatible with miniaturized, portable, and multifunctional analytical platlate proteins, organelles, viral capsids, and biological cells, among others.

Analytes of environmental or biological origin occur in complex matrices, which complicates their separation and detection. For this reason, sample preparation methods such as extraction are a crucial step prior to chromatographic analysis. The goals of sample preparation technologies are purification and pre-enrichment of target analytes to be separated and then detected by the instrument. Purification reduces the concentration of interfering matrix substances, which affects separation and measurement through a decrease in sensitivity and a significant increase in maintenance, loss in chromatographic efficiency, and distortion of peak shape. In addition, high-abundance species might overwhelm the column. Extraction accomplishes purification and pre-enrichment by partition of the analyte into or onto an extraction phase.

Advances in extraction seek to improve selectivity and to boost pre-enrichment of the analyte through its increased mass transport to and uptake into or onto the extraction phase. For systems in which analytes or interferents are charged, integration of electric fields normal to the phase boundary can be leveraged to improve these features of the extraction. Electric fields can be generated and modulated by a simple pair of electrodes, and are by nature a green, cost-effective, and user-friendly addition to an extraction protocol. For this reason, the use of electric fields in extraction is an important modern trend in analytical chemistry. Although many electric field–assisted separation techniques have been developed and studied in depth, such as electrodialysis, gel electrophoresis, capillary electrophoresis, and capillary electrochromatography, the use of electric fields in extraction is still an underdeveloped area.

In the context of extraction, there are three areas where an applied voltage can be employed. Electric fields can be used to drive more rapid mass transport of charged analytes to the extraction phase, as well as partition of a species with a certain charge to increase selectivity of the extraction. Further, electrosynthesis can be utilized to synthesize and prepare membranes and solid-phase sorbents for extraction. It is notable that use of an electric field to perform any of these three functions can be readily implemented in microfluidic devices to create highly integrated analytical platforms.

Using an electric field in extraction has several advantages, such as improved selectivity for transfer of ionized species, efficient matrix cleanup, and modulation of the sample preparation process for potentially exhaustive extraction of target species. Electric fields have been employed in both solid-phase and liquid–liquid extractions.

Electric fields have been employed to enhance solid-based extraction by either direct manipulation of extraction or by migration of charged species to the interface during the extraction phase or away from the interface during the elution stage. Compared to traditional solid-phase extraction, electric field-enhanced extraction provides a new dimension to separation art, making it more versatile and dynamic.

November 2022 | LCGC North America

Pitfalls in Proteomics: Avoiding Problems That Can Occur Before Data Acquisition Begins

Class Is Back in Session: More Questions on Your Extraction Knowledge

Selectivity and Sensitivity: The Electron Capture Detector (ECD), Its Unique Inventor James Lovelock (1919–2022), and GAIA

On Replication in Biopharmaceutical Analysis

Tools for Investigating the Expanding Per- and Polyfluoroalkyl Substances (PFAS) Universe

Sample Preparation by Electric Field–Assisted Extraction

Overcoming Incomplete Peptide Mapping of Antibody Complementarity-Determining Regions with Alternate Digestion Workflows
